22" SPADE PRO FRAME FRAME & FORK KIT, GOLD
22" SPADE PRO FRAME FRAME & FORK KIT, GOLD - Gold is backordered and will ship as soon as it is back in stock.
Delivery and Shipping
Delivery and Shipping
Add some general information about your delivery and shipping policies.
Description
Description
FRAME:
FEATURES:The 100% Chromoly frame is designed for 22" trail, street and park with our unique 22” geometry. This frame rides and feels like a 20 inch Pro level frame with a little more cockpit room.
HEADSET TYPE:Integrated (Campy)
GYRO TABS:No
BRAKE MOUNTS: Removable (Included)
BB TYPE: Mid
BB HEIGHT: 12.25"
CHAINSTAY LENGTH: 14.1" CtoC
HEADTUBE ANGLE:74.25°
SEATTUBE ANGLE: 71°
SEAT POST SIZE: 25.4mm
SEAT CLAMP:Integrated
DROPOUT SIZE: 14mm
WEIGHT: 5.35 lbs
GEOMETRY: TT: 22.25″ CS: 14.10″ HT: 74.25° ST: 71° SO: 9.10″ BB: 12.25" (+25mm offset)
FORK:
FEATURES: Heat-treated 31.8mm tapered Chromoly legs, one-piece Chromoly steerer tube w/ integrated crown race, 5mm dropouts for 3/8” axles
Alloy Vortex top cap included.
STEERER TUBE LENGTH:165mm
OFFSET: 28.0mm
COMPRESSION BOLT: Alloy M24x1.5mm
COMRESSION BOLT TOOL:6mm Allen Key
WEIGHT: 34.0 oz
